Hastelloy C276 Perforated sheets Supplier
TABLE OF CONTENTS
- Hastelloy C276 Perforated Sheets Supplier
- Specifications of Hastelloy C276 Perforated Sheets
- Types of Hastelloy C276 Perforated Sheets
- Chemical Composition of Hastelloy C276 Perforated Sheets
- Mechanical & Physical Properties of Hastelloy C276 Perforated Sheets
- Equivalent Grades of Hastelloy C276 Perforated Sheets
- Related Products
- Frequently Asked Questions
Specifications of Hastelloy C276 Perforated sheets
|
Specification |
Details |
|
Standard |
ASTM / ASME SB 575 |
|
Dimensions |
ASTM, ASME and API |
|
Range |
0.5 mm to 200 mm Thick |
|
Hardness |
Soft, Hard, Half Hard, Quarter Hard, Spring Hard |
|
Grade |
Hastelloy C276 (UNS N10276) |
|
Length |
Single Random, Double Random & Cut Length |
|
Form |
Round Holes Perforated Sheet, Square Holes Perforated Sheet, Slotted Holes Perforated Sheet, Ornamental Perforated Sheet, Decorative Perforated Sheet, Custom Perforated Sheet, Uniform Surface Chequered Sheet |
|
Finish |
Hot Rolled Plate (HR), Cold Rolled Sheet (CR), 2B, 2D, BA, No. 8, Satin (with Plastic Coated) |
Need ASTM B575 Hastelloy C276 Perforated Sheet for your project? Request a quote. Our technical team responds within 24 hours.
Types of Hastelloy C276 Perforated sheets
-
Hastelloy C276 Chequered Sheets
-
ASTM, ASME, API Sheet
-
Hastelloy C276 Perforated and Chequered Sheet
-
Hastelloy UNS N06022 Perforated Sheet
-
Hastelloy C276 Sheet
-
ASME Hastelloy C276 Sheet
-
Hastelloy UNS N10276 Perforated Sheet
-
Hastelloy Alloy C276 Sheets
-
WNR 2.4819 Chequered Sheet
-
JIS NW 0276 Alloy Sheet
-
Hastelloy DIN 2.4819 Cold Rolled Sheets
-
Hastelloy Perforated Sheet
-
Hastelloy ASTM B575 Perforated Sheets
Chemical Composition of Hastelloy C276 Perforated sheets
|
|
|
|
Carbon |
0.01 max |
|
Chromium |
14.5 – 16.5 |
|
Cobalt |
2.5 max |
|
Iron |
4 – 7 |
|
Manganese |
1 max |
|
Molybdenum |
15 – 17 |
|
Phosphorus |
0.015 max |
|
Silicon |
0.08 max |
|
Sulphur |
0.01 max |
|
Tungsten |
3 – 4.5 |
|
Vanadium |
0.35 max |
|
Nickel |
Balance |
Mechanical & Physical Properties of Hastelloy C276 Perforated sheets
|
Grades |
Density |
Melting Point |
Tensile Strength |
Yield Strength (0.2%Offset) |
Elongation |
|
C276 |
8.89 g/cm3 |
1370 °C (2550 °F) |
Psi – 1,15,000 , MPa –790 |
Psi – 52,000 , MPa – 355 |
40 % |
Equivalent Grades of Hastelloy C276 Perforated sheets
|
STANDARD |
WERKSTOFF NR. |
UNS |
JIS |
BS |
GOST |
EN |
OR |
|
Hastelloy C276 |
2.4819 |
N10276 |
NW 0276 |
– |
ХН65МВУ |
NiMo16Cr15W |
ЭП760 |
Hastelloy C276 Perforated Sheets Applications
Hastelloy C276 Perforated Sheet: Dimensional Specifications and Sheet Size
The table below summarises the standard and custom dimensional parameters for ASTM B575 Hastelloy C276 perforated plate and sheet. UNS N10276 perforated sheet thickness ranges from 0.5 mm up to 10 mm depending on hole size and open area requirements. DIN 2.4819 perforated plate in thicker gauges is typically supplied in the hot rolled and annealed condition.
|
Parameter |
Minimum |
Maximum |
Standard Sizes |
Edge / Finish |
|
Thickness |
0.5 mm |
10 mm |
1.0 mm, 1.5 mm, 2.0 mm, 3.0 mm, 5.0 mm |
As rolled |
|
Sheet Width |
500 mm |
2500 mm |
1000 mm, 1250 mm, 1500 mm, 2000 mm |
Plain / Mill edge |
|
Sheet Length |
1000 mm |
12500 mm |
2000 mm, 2500 mm, 6000 mm |
Cut to size |
|
Edge Type |
Plain |
Margin Border |
Plain, Border margin (all four sides) |
Deburred / ground |
|
Surface Finish |
2B (Cold Rolled) |
BA / No.8 Mirror |
2B, 2D, BA, HR, No.8 |
Plastic coated optional |
|
Coil Form |
0.5 mm thick |
3.0 mm thick |
Hastelloy C276 perforated coil available |
Slit to width on request |
Hastelloy C276 Perforated Sheet: Dimensional Specifications and Sheet Size
The table below summarises the standard and custom dimensional parameters for ASTM B575 Hastelloy C276 perforated plate and sheet. UNS N10276 perforated sheet thickness ranges from 0.5 mm up to 10 mm depending on hole size and open area requirements. DIN 2.4819 perforated plate in thicker gauges is typically supplied in the hot rolled and annealed condition.
|
Parameter |
Minimum |
Maximum |
Standard Sizes |
Edge / Finish |
|
Thickness |
0.5 mm |
10 mm |
1.0 mm, 1.5 mm, 2.0 mm, 3.0 mm, 5.0 mm |
As rolled |
|
Sheet Width |
500 mm |
2500 mm |
1000 mm, 1250 mm, 1500 mm, 2000 mm |
Plain / Mill edge |
|
Sheet Length |
1000 mm |
12500 mm |
2000 mm, 2500 mm, 6000 mm |
Cut to size |
|
Edge Type |
Plain |
Margin Border |
Plain, Border margin (all four sides) |
Deburred / ground |
|
Surface Finish |
2B (Cold Rolled) |
BA / No.8 Mirror |
2B, 2D, BA, HR, No.8 |
Plastic coated optional |
|
Coil Form |
0.5 mm thick |
3.0 mm thick |
Hastelloy C276 perforated coil available |
Slit to width on request |
Related Products
- Hastelloy C276 Pipes and Hastelloy C276 Tube
- Hastelloy C22 Pipes & Hastelloy C22 Tubes
- Hastelloy B2 Pipes Tube Supplier
- Hastelloy C276 Buttweld Fittings
- Hastelloy C22, Hastelloy B2 Buttweld Fittings
- Hastelloy C276 Flanges
- Hastelloy C22, Hastelloy B2 Flanges
- Hastelloy C276 Perforated Sheet
- Hastelloy C22, Hastelloy B2 Perforated Sheet
- Hastelloy C276 Fasteners
- Hastelloy C22 Fasteners & Hastelloy B2 Fasteners
- Hastelloy C276 Round Bars And Wires
- Hastelloy C22 Round Bars & Hastelloy B2 Wires
- Hastelloy C276 Forged Fittings
- Hastelloy C22, Hastelloy B2 Forged Fittings
- Hastelloy C276 Instrumentation Valves
- Hastelloy C22, Hastelloy B2 Instrumentation Valve
- Hastelloy C276 Olets
- Hastelloy C22, Hastelloy B2 Olets
- Hastelloy C276 Pipe Spools
- Hastelloy C22, Hastelloy B2 Pipe Spools
- Hastelloy C276 Wiremesh
- Hastelloy C22, Hastelloy B2 Wiremesh
- Hastelloy C276 Plates And Hastelloy C276 Sheets
- Hastelloy C22, Hastelloy B2 Plates And Hastelloy C22, Hastelloy B2 Sheets
- Hastelloy C276 Filler Wire
- Hastelloy C22, Hastelloy B2 Filler Wire Supplier
- Hastelloy C276 Compression Tube Fittings
- Hastelloy C22, Hastelloy B2 Compression Tube Fittings
- Hastelloy C276 Long Radius Bend
- Hastelloy C22, Hastelloy B2 Long Radius Bends
Frequently Asked Questions
What are the standard hole sizes for Hastelloy C276 perforated sheet?
Kalpataru Piping supplies Hastelloy C276 perforated sheet with round hole diameters from 0.5 mm to 50 mm, square holes from 1.0 mm to 40 mm and slotted holes from 1.0 mm width to 100 mm length. The most common hole diameters for industrial filtration are 1.0 mm, 1.5 mm, 2.0 mm, 3.0 mm and 5.0 mm in staggered 60 degree pitch. Custom hole sizes and pitch combinations are available on request.
When should I choose a round hole versus a slotted hole Hastelloy C276 perforated sheet?
Round hole Hastelloy C276 perforated sheet gives the highest open area for a given pitch and is preferred for FGD scrubber screens, demister pads and filter baskets where flow resistance must be minimised and particles are roughly spherical. Slotted hole UNS N10276 perforated sheet is preferred for pulp screens, paper machine drainage elements and grain separator duties where elongated fibres or particles must be retained while liquid passes freely. Slotted holes also allow the sheet to flex slightly in the length direction, which can be advantageous in thermally cycled equipment.
What is the maximum sheet thickness available for Hastelloy C276 perforated sheet?
Kalpataru Piping regularly supplies ASTM B575 UNS N10276 perforated sheet in thicknesses up to 10 mm. Above 6 mm the sheet is classified as perforated plate and is typically supplied in the hot rolled and annealed condition with 2D surface finish. For thicknesses beyond 10 mm, Hastelloy C276 solid plate from the parent product range is available, and Kalpataru Piping can evaluate custom perforation feasibility on a job-by-job basis. Contact us with your hastelloy c276 perforated sheet thickness requirement for a prompt technical response.
Is Hastelloy C276 perforated sheet available in coil form?
Yes. Hastelloy C276 perforated coil is available in thicknesses from 0.5 mm to 3.0 mm with round hole staggered pitch patterns. Perforated coil is commonly used for reel-to-reel stamping of filter discs, EMI shielding strips and flexible screening elements. Minimum coil weight and slit width are subject to order quantity. Contact Kalpataru Piping for coil specifications and lead times.
Request a Quote for Hastelloy C276 Perforated Sheet
Kalpataru Piping maintains ready stock of UNS N10276 Hastelloy C276 Perforated Sheet in all standard and custom sizes, including round hole, square hole, slotted hole, decorative perforated sheets, and other custom perforated metal sheet configurations.
Get an immediate price for your Hastelloy C276 perforated sheet requirement. Our technical team will review your specifications and respond within 24 hours with the best pricing and delivery options.
